Specifications
1. XLR wireless DMX512 receiver
2. Used as DMX512 signal reciever
3. Plug-and-play function
4. 3pin female plug
Features
1. LED to display working condition
2. Easy to use wireless DMX system in a convenient form factor
3. Outstanding range & reliability
4. Compatible with all DMX512 compliant equipment
5. Supports up to 7 simultaneous DMX universes per location
(Multiple systems required)
Specifications
1. Transmitter/Receiver band: 2.4GHz ISM (2.4-2.52Ghz)
2. 126 channels jumping frequency self-moving
3. Channels: 512
4. Frequency Groups: 7
5: Transmitter power: 20dBm
6. Receiver sensitivity: -94dBm
Product Feature
Product name: 2.4G wireless DMX512 R/T
Tricolor LED displaying
126 channels jumping frenquecy automaticly,high anti-jamming
ability. to ensure works reliability
7 groups ID code settable,User can use 7 groups individual wireless
net without any interfere each other in the same place...
Input voltage: 5VDC 500mA MIN
Communication distance: 400M(visible distance , it has some
different base on environment)
Work frequency section: 2.4G ISM,126 channels.frequency section
Max transmitting power rate: 20dBm
Receiver sensitive: -94dBm
Signal port: 3pin female plug
Operating manual
ID code and LED color corresponding relateship:
l 1: RED
l 2: GREEN
l 3: RED+GREED
l 4: BLUE
l 5: RED+BLUE
l 6: GREEN+BLUE
l 7: RED+GREED+BLUE
Press key 1 time to indicate ID setting,,Press again to set IC,then
ID value adding 1 each time.by press
Working condition:
l LED constant lit up: no DMX or wireless singal.
l Red LED flash: transmitting.
l Green LED flash: receiveing
RF frequency- - - - - - - - - - - - 2. 400-2. 525 G,total 126
channels,it’s searching automaticly,
ID Code- - - -“1-7” groups ID code,press ”KEY” for setting,it only
can works under same ID code.of transmitter and receiver.
Brief:
DMX512 wireless receiver/transmitter transmits standard DMX512
protocol data (generated by console )by wireless way, which solves
lighting control issues of wireless transmitting completely between
console and lighting, lighting and lighting and so on, It get rid
of connecting cable limited completely
And also can ensure without any time delay when signal data is
transmitting, signal data is real time and reliably.
This product adopt 2.4G ISM frequency section( global opening
section) without permission limited
High effective GFSK modulate,communication design ; 126 channels
jumping frenquecy automaticly,high anti-jamming ability.
